Stryker X8000 Service Manual

39
7.0 LED power switch
S
e
q
.
T
a
s
k
D
e
s
c
r
i
p
t
i
o
n
F
i
g
u
r
e
T
o
o
l
s
N
e
e
d
e
d
P
a
r
t
s
720
Remove Chassis Cover
from Chassis (procedure
1.0).
730
Remove Jaw Handle from
Jaw Handle Key and Pinion
Sha

(procedure 6.0, seq
700).
740
Remove Jaw Handle Key
from Pinion Sha

groove.
•
Jaw
Handle
Key, X7000
(641)
•
X8000
Pinion
Sha

(298)
750
Unsnap Front Panel from
Chassis as shown.
•
X8000
Front
Panel (337)
•
X8000
Chassis
(343)
760
Unpl
ug Control B
oard/
Display Board Cable
-565 from Display Board
connector J20.
• Control
Board/Display
Board Cable
Assembly
(5-Pin 5-Wire)
(565)
•
X8000
Display
Board (336)
