Stryker X8000 - Display Board

43
8.0 Display Board
S
e
q
.
T
a
s
k
D
e
s
c
r
i
p
t
i
o
n
F
i
g
u
r
e
T
o
o
l
s
N
e
e
d
e
d
P
a
r
t
s
870
Remove Chassis Cover
from Chassis (procedure
1.0).
880
Disconnect front panel
from unit (procedure 7.0,
seq 730 - 770).
890
Unplug Front Panel Overlay
Cable from Display Board
connector J20.
•
Front
Panel
Overlay Cable
•
Display
Board
(336)
900
Unpl
ug Beam
Sensor-ESST/
Display Board Cable from
Display Board connector
J17 as shown.
•
Beam
Sensor-
ESST/Display
Board Cable
(573)
•
Display
Board
(336)
910
Unsnap Display Board
from Front Panel as shown.
Remove Display Board
from unit.
•
Display
Board
(336)
•
Front
Panel
Assembly
920
Peel o
ff
LCD Cover and
snap on new Display Board
to Front Panel with LCD
facing out of Front Panel as
shown.
•
Display
Board
(336)
•
Front
Panel
Assembly
