Stulz CyberCool - 3.8 Circuit scheme

17 © STULZ GmbH – all rights reserved EN/09.2017/G44
cybercool indoor chiller original instructions
Pressure sensor
Temperature sensor
High pressure limiter
Low pressure switch
Pressure gauge
Flow switch / monitor
Antifreeze thermostat
3.8 Circuit scheme
Non-return valve
Filter drier
Sight glass
Rotalock stop valve with cap
Pressure relief valve
Schrader valve
3-way motorized valve
2-way motorized valve
Electric reheat
Solenoid valve
Manual stop valve
Automatic deventilation valve
Electronical expansion valve
Stop valve with cap and Schrader valve
Legend
