cybercool indoor chiller original instructions
NOTICE
Water remaining from the test run may escape when the protective caps are removed.
• remove the protective caps or sealing disks of the screwed connections.
• screw the lines of the external system to the lines of the unit respecting the designation at the unit (inlet/
outlet).
• insulate the water pipes with the diffusion tight insulating material, to prevent the introduction of ambient air
heat and the formation of condensate at the pipes.
Unit rear side
Top view
Cooling medium:
Inlet
Outlet
Chilled water
Outlet
Inlet
safety valve
drain
5.3.2.2 Position of the water piping connections for version GE
