Stulz Ultra Series User Manual

STULZ Ultra-Series Humidifier Controller
42 (August, 2013)
Limit Air Temp:
Enable Type: 4-20mA
Minimum X: 20.0
Maximum X: 100.0
Minimum Y: 0.0°c
Maximum Y: 100.0°c
X: 39.1 Y: 74.6°F
Limit Air Humid:
Enable Type: 4-20mA
Minimum X: 20.0
Maximum X: 100.0
Minimum Y: 0.0%RH
Maximum Y: 100.0%RH
X: 51.2 Y: 74.6%RH
Airspeed:
Enable Type: 4-20mA
Minimum X: 20.0
Maximum X: 100.0
Minimum Y: 0.0
Maximum Y: 2000.0
X: 33.5 Y: 337.4
NTC2 Temp:
Enable
Minimum X: 0.0
Maximum X: 100.0
Minimum Y: 0.0°c
M
aximum Y: 100.0°c
X
: 13.8 Y: 56.6°F
NTC3 Temp:
Enable
Minimum X: 0.0
Maximum X: 100.0
Minimum Y: 0.0°c
M
aximum Y: 100.0°c
X
: 13.8 Y: 56.6°F
NTC4 Temp:
Enable
Minimum X: 0.0
Maximum X: 100.0
Minimum Y: 0.0°c
M
aximum Y: 100.0°c
X
: 13.8 Y: 56.6°F
Sensors
DigitalIn
Options
5.6.1.1.4 Limit Temperature Setup
5.6.1.1.5 Limit Humidity Setup
5.6.1.1.6 Airspeed Setup
5.6.1.1.7 Cabinet Temperature Setup
The cabinet temperature sensor is always enabled and is
always an NTC sensor.
5.6.1.1.8 NTC2 Temperature Setup
NTC2, NTC3 and NTC4 are always NTC sensors.
5.6.1.1.9 NTC3 Temperature Setup
5.6.1.1.10 NTC4 Temperature Setup
5.6.1.2 Factory Digital Input Setup
The Factory Digital Input setup screens allow modifying
the nature of the input. Digital inputs are switch inputs tied
to ground or open.
SENSOR INPUT SETUP
SENSOR INPUT SETUP
SENSOR INPUT SETUP
SENSOR INPUT SETUP
Cabinet Air Temp:
Minimum X: 0.0
Maximum X: 100.0
Minimum Y: 0.0°c
Maximum Y: 100.0°c
X: 13.8 Y: 56.6°F
SENSOR INPUT SETUP
SENSOR INPUT SETUP
SENSOR INPUT SETUP
SENSOR INPUT SETUP
FACTORY.
