6. Select “ Set” by operating the “ ”
switch and confirm the setting by pulling
the “
/SET” switch toward you.
7. The system will notify you that the
setting is complete.
! Triple meter setting
1. Perform the preparation steps accord-
ing to “Preparation for screen settings”
F3-59.
2. Operate the “ ” or “ ” switch to
select the “Triple Meter” item. Then pull
the “
/SET” switch toward you.
3. Select the setting location (left, center
or right) by operating the “
” or “ ”
switch. Then pull the “
/SET” switch
toward you.
NOTE
The same item cannot be selected for
the left, center or right location.
Instruments and controls/Multi function display
– CONTINUED –
3-63
