(3) Push the stoppers located on the
both sides of the glove box to remove
the glove box.
2. Remove the air filter.
3. Replace the air filter element with a
new one.
CAUTION
The arrow mark on the filter must
point UP.
4. Reinstall the glove box, and connect
the damper shaft.
5. Close the glove box.
6. LABEL installation
(1) Fill out the in formation o n the
service label (small).
Climate control 4-15
