. Frontal airbag module (driver’s side)
. Frontal airbag module (front passen-
ger’s side)
. Side airbag sensor (center pillar right-
hand side – if equipped)
. Side airbag sensor (center pillar left-
hand side – if equipped)
. Side airbag module (driver’s side – if
equipped)
. Side airbag module (front passenger’s
side – if equipped)
. Curta in airbag sensor (rear wheel
house right-hand side – if equipped)
. Curta in airbag sensor (rear wheel
house left-hand side – if equipped)
. Curtain airbag module (right-hand side
– if equipped)
. Curtain airbag module (left-hand side –
if equipped)
. Satellite safing sensor (under the rear
center seat – if equipped)
. Seatbelt pretensioner (driver’s side)
. Lap belt pretensioner (driver’s side –
Australia models only)
. Seatbelt pretensioner (front passen-
ger’s side)
. All related wiring
WARNING
If the warning light exhibits any of
the following conditions, there may
be a malfunction in the seatbelt
pretensioners and/or SRS airbag
system. We recommend that you
have the system checked immedi-
ately by your nearest SUBARU deal-
er. Unless checked and properly
repaired, the seatbelt pretensioners
and/or SRS airbags will operate
improperly (e.g. SRS airbags may
inflate in a very minor collision or
not inflate in a severe collision),
which may increase the risk of
injury.
. Flashing or flickering of the warn-
ing light
. No illumination of the warning
light when the ignition switch is
first turned to the “ON” position
. Continuous illumination of the
warning light
. Illumination of the warning light
while driving
& SRS airbag system servicing
WARNING
. When discarding an airbag mod-
ule or scrapping the entire vehi-
cle damaged by a collision, we
recommend that you consult
your SUBARU dealer.
. The SRS airbag has no user-
serviceable parts. Do not use
electrical test equipment on any
circuit related to the SRS airbag
system. For required servicing of
the SRS airbag, we recommend
that you consult your nearest
SUBARU dealer. Tampering with
or disconnecting the system’s
wiring could result in accidental
inflation of the SRS airbag or
could make the system inopera-
tive, which may result in serious
injury.
CAUTION
If you need service or repair in areas
listed as follows, we recommend
that you have the work performed
by an authorized SUBARU dealer.
The SRS airbag control module,
impact sensors and airbag modules
Seat, seatbelt and SRS airbags 1-55
