Power Assisted System (Power Steering)
POWER STEERING SYSTEM
PS-7
3.0 MODEL
(1) Power cylinder (11) Steering wheel
(2) Rack piston (12) Tank
(3) Rack shaft (13) Vane pump
(4) Pinion shaft (14) Relief valve
(5) Chamber A (15) Hose A
(6) Chamber B (16) Hose B
(7) Pipe A (17) Pump control valve
(8) Pipe B (18) Fluid pump
(9) Rotary control valve (19) Engine
(10) Steering shaft
S4H0023B
