Fastir Parts Assembly Manual
63
Stationary Outside Carriage
Table 28 - Stationary Outside Carriage Parts List
Ref #
Description
Qty
Comp #
Comp #
4-1/2”
Crosstube
5-1/2”
Crosstube
1
Outside Carriage
1
A5250
A6140
2
Roller Bearing
1
J0045
J0045
3
Bearing Block
4
A8507
A8507
3A
Screws, 1-1/8”
8
J0463
J0463
4
Machine screw, #10-24 plated
1
J0514
J0514
5
Nut, #10-24 plated
1
J0985
J0985
6
Bolt, 5/16” x 1-1/4”
1
J0550
J0550
7
Cord Hanger
1
A52121
A52121
8
Bearing, 1” OD, .3125 ID RF - 16 - PP INA
2
J00425
J00425
9
Lockwasher, 5/16”
8
J1200
J1200
10
Nut, 5/16”- 18
11
J1002
J1002
11
Stationary carriage PLT
1
A5245
A6115
12
Screw, 5/16”- 18 x 1”
7
J0527
J0527
13
Flatwasher, 5/16”
6
J1111
J1111
14
Motor Mount
1
A5209
A5209
15
Spring, Compr. 1-1/2” CLx1/2ID
2
J2365
J2365
16
Hairpin Clip
2
J5410
J5410
17
Motor “O” 1-1/2hp, 230V 1ph (Includes Pulley & Key)
1
A7725
A7725
Motor ”O” 1-1/2hp, 230V 3ph (Includes Pulley & Key)
1
A7729
A7729
18
Pulley, 2-3/4” x 7/8 “A”
1
J0295
J0295
19
Key, 3/16” sq. x ¾”
1
A7522
A7522
20
End Carriage Shield
1
A8508
A6120
21
Down Auger 15’6” (std, other sizes opt.)
1
A4210
A4210
22
Flinger
1
A5616
A5616
23
U-Bolt, 5/16”- 18 x 1-3/4”
1
J0810
J0810
24
Flange Bearing 1” FHFT 205-16
2
J0003
J0003
25
Locking Collar
2
J0067
J0067
26
Bolt, 7/16”- 14 x 1-1/2”
4
J0710
J0710
27
Lockwasher, 7/16”
4
J1210
J1210
28
Nut, 7/16”- 14
4
J1035
J1035
29
Pulley, 9” “A” Groove w/pin hole
1
J0355
J0355
30
Rollpin 5/16” x 2-1/4”
1
J1510
J1510
31
Tilt Switch Brkt. w/clip (New)
1
A5449
A5449
32
Tilt Switch 7MP 1-46
1
A5445
A5445
Tilt Switch, Brkt, & Cord (Not shown)
1
Varies by unit, See page 69.
33
Push Nut, 7/16", Stud
2
J1036
J1036
34
Belt
1
J0179
J0195
35
Bolt, Carriage
2
J07601
J07611
37
Nut, 1/2”- 13 Hex Head
6
J1040
J1040
38
39
Decal, Warning
Decal, Replace Shield
1
1
L0284
L0271
L0284
L0271
40
Bolt, 1/4”-20 x ¾”
2
J0505
J0505
41
Plastic Cord Holder
1
A5637
A5637
