MATERIALS REQUIRED
Before beginning to install this product, ensure that all required components are present by checking the Shipping
List section below. Also, compare carton contents against labels on cartons and ensure crosstube supplied is
correct size for bin.
Shipping List
Table 1 - Major Parts List
Fastir
Fastir Plus
Description
Qty - Single
Qty - Double
Qty - Triple
Qty - Triple
Qty - Quad
Qty - Quint
Fastir Crosstube
1
1
1
1
1
1
Hanger Pipe
1
1
1
1
1
1
Top Hanger
1
1
1
1
1
1
Outside Cord Hanger
1
1
1
1
1
1
Tie Bar(s)
-
2
4
2
4
6
Track
1
1
1
1
1
1
Down Auger
1
2
3
3
4
5
Hardware Ctn #1
1
1
1
1
1
1
Hardware Ctn #2
1
1
1
1
1
1
Hardware Ctn #3
-
-
-
1
1
1
Stationary Auger Kit
-
-
-
1
1
1
Stabilizer Arm Kit (Standard with
units ordered after 2007)
1
1
1
1
1
1
Table 2 - Fastir/Fastir Plus Basic Hardware Carton Part Numbers
Hardware Carton #
Comp #
Single
Double
Triple
Quad
Quint (Fastir Plus)
4-1/2”
5-1/2”
4-1/2”
5-1/2”
4-1/2”
5-1/2”
4-1/2”
5-1/2”
4-1/2”
5-1/2”
1
A8490
-
A8491
A84912
A8492
A84922
A8493
A84933
-
A84935
2
Varies by bin diameter and motor phase and voltage
3*
* For Fastir Plus units only
A3424
A34242
A3424
A34242
A3424
A34242
Table 3 - Fastir/Fastir Plus Basic Hardware Carton #1 Contents
Description
Comp #
Qty
4-1/2” Crosstube
5-1/2” Crosstube
Single
Double
Triple
Quad
Quint
Safety Decal Pkg.
A3399
A3399
1
1
1
1
1
Motor Mount
A5209
A5209
1
2
3
4
5
Cast Junction Elec. Box
A5612
A5612
1
1
1
1
1
Flinger
A5616
A5616
1
2
3
4
5
Cord Support Strap
A6121
A6121
1
1
1
1*
1*
Parts Sack Single
A6806
A6806
1
-
-
-
-
Parts Sack Double
A6807
A6807
-
1
-
-
-
Parts Sack Triple
A6808
A6808
-
-
1
1
1
Offset (Center) Hanger
A7504
A7504
1
1
1
1
1
Hanger
A7509
A7509
2
2
2
2
2
Rev. Carriage Plate
A80342
A8060
4
4
4
4
4
Primary Carriage
A8500
-
1
-
-
-
-
Primary Carriage
A8501
A6130
-
1
1
1
1
Satellite Carriage
A8502
A6135
-
1
2
3
4
Shield
A8508
A6120
1
2
3
4
5
Flange Bearing “1”
J0003
J0003
2
4
6
8
10
Belt
J0179
J0195
1
2
3
4
5
Pulley, 9”, Sng, A Groove
J0355
J0355
1
2
3
4
5
Prevent Voiding Warranty
L0249
L0249
1
1
1
1
1
Imp. Grain Level Warning
L0304
L0304
1
1
1
1
1
Sukup Logo
L03171
L03171
-
1
1
1
1
Manual
L1413
L1413
-
1
1
1
1
Wire Ties, Bundle
L9999
L9999
1
2
3
4
5
*Includes 2 with Fastir Plus
