Fastir Parts Assembly Manual
Satellite Wrap-Around Carriage
Table 27 - Satellite Wrap-Around Carriage Parts List
Crosstube, Fastir, 18’-18’7”
Crosstube, Fastir, 21’-21’8”
Crosstube, Fastir, 24’-24’9”
Crosstube, Fastir, 27’-27’10”
Crosstube, Fastir, 30’-31’
Crosstube, Fastir, 33’-34’
Crosstube, Fastir, 36’-37’1”
Crosstube, Fastir, 42’-42’8”
*Inner Slug, 1-1/4” shaft
Satellite Carriage (With bearing block)
Satellite Carriage (With bearing)
Spring Comp., 1-1/2” CL x 1/2” ID
Motor “O” 1-1/2HP 1ph 230V (See page 69).
Motor “B” 1-1/2HP 1ph 230V “ “ “ “
Motor “O” 1-1/2HP 3ph 230V “ “ “ “
Motor “B” 1-1/2HP 3ph 230V “ “ “ “
Motor “O” 1-1/2HP 3ph 460V “ “ “ “
Motor “B” 1-1/2HP 3ph 460V “ “ “ “
Pulley, 2-3/4” x 7/8” “A”
*Pulley, 3” x 7/8” single “A” Groove
Shoulder Bolt, 5/16”, 3/4”, 1/4-20 thread
Tilt Switch, Bracket, & Cord (Not shown)
Varies by unit, See page 69.
Down Auger 15’6” Standard (Other sizes optional)
Flange Bearing 1” FHFT 205-16
Bolt, 7/16”- 14 x 1-1/2” GR5
U-Bolt, 5/16”- 18 x 1-3/4”
Pulley 9” “A” Groove w/ Pin Hole
Tie Bar (Specify size needed)
Varies, see pages 16 & 18.
Outer Slug w/ drive wheel
Locknut, 1/4-20, PLT, Nylon
Varies, see pages 16 & 18
Bearing Block (Not shown)
Bearing Ball Transfer (Not Shown)
Screws, #8 Stainless Steel (Not Shown)
Cord Support Strap
Shoulder Bolt, 8 mm, 10, 6 mm thread
* For required receptacle, see page 59.
