Sukup Fastir - Page 59

Fastir Parts Assembly Manual
59
Primary Wrap-Around Carriage
Table 26 - Primary Wrap-Around Carriage Parts List
Ref #
Description
Qty
Comp #
Comp #
4-1/2” Crosstubes
5-1/2” Crosstubes
1
Primary Carriage
1
A8501
A6130
2
Bearing Block
4
A8507
A8507
2A
Screw, 1-1/8”
8
J0463
J0463
3
Machine Screw #10-24 x 1/2”
1
J0514
J0514
4
Nut, Hex, #10-24 Plated
1
J0985
J0985
5
Reversing Carriage Plate
4
A80342
A8060
6
Cord Holder
1
A5637
A5637
7
Motor Mount
1
A5209
A5209
8
Spring Comp., 1-1/2” CL x ½” ID
2
J2365
J2365
9
Hairpin Clip
2
J5410
J5410
10
Motor “S” 1-1/2hp 1ph 230V
A7721
A7721
Motor “A” 1-1/2hp 1ph 230V
A7721
A7721
Motor “S” 1-1/2hp 3ph 230V
A7732
A7732
Motor “A” 1-1/2hp 3ph 230V
A7732
A7732
Motor “S” 1-1/2hp 3ph 460V
A7735
A7735
Motor “A” 1-1/2hp 3ph 460V
A7735
A7735
(Motor includes pulley and key)
(“A” Motors wired w/ 9’6” replacement leads)
See page 68 for correct cord lengths & #s
Receptacles (Not Shown)
Plug, Male, 3-Prong - 1ph
J3715
J3715
Plug, Female, 3-Prong, Arm - 1ph
J3720
J3720
Plug, Male, 4-Prong, Arm - 3ph
J3725
J3725
Plug, Female, 4-Prong, Arm - 3ph
J3730
J3730
11
Pulley, 2-3/4” x 7/8” “A”
1
J0295
J0295
12
Key Stock, 3/16” sq. x 3/4”
1
A7522
A7522
13
Center Carriage Shield
1
A8508
A6120
14
Down Auger - 15’6” Standard, other sizes optional
1
A4210
A4210
15
Flinger
1
A5616
A5616
16
U-Bolt, 5/16”- 18 x 1-3/4”
1
J0810
J0810
17
Flange Bearing, 1” FHFT 205-16
2
J0003
J0003
18
Locking Collar
2
J0067
J0067
19
Bolt, 7/16” -14 x 1-1/2”
4
J0710
J0710
20
Lockwasher, 7/16”
4
J1210
J1210
21
Nut, 7/16”- 14
4
J1035
J1035
22
Pulley, 9” “A” Groove w/pin hole
1
J0355
J0355
23
Rollpin 5/16” x 2-1/4”
1
J1510
J1510
24
Push Nut, 7/16”, Stud
2
J1036
J1036
28
Belt
1
J0179
J0195
29
Bolt, 3/8” -16 x 1-3/4”, PLT GR5, Tap
4
J0640
J0640
30
Nut, 3/8”-16
4
J1020
J1020
31
Lockwasher, 3/8” Split
4
J1205
J1205
33
Bolt, 5/16”- 18 x 1”
6
J0527
J0527
34
Flatwasher, 5/16”
8
J1111
J1111
35
Lockwasher, 5/16”
6
J1200
J1200
36
Nut, 5/16”- 18
8
J1002
J1002
37
Decal, Replace Shield
1
L0271
L0271
38
Decal, Warning
1
L0284
L0284
39
Outer Slug w/ drive wheel
1
A8085
A8089
40
Bolt,1/4”- 20 x ¾”
2
J0505
J0505
41
Bolt, Carriage
2
J07592
J07611
42
Nut, 1/2”- 13, Hex Head
6
J1040
J1040
43
Cord Support Strap
1
A6121
A6121
