Materials Required
9
Table 4 - Fastir/Fastir Plus Hardware Carton #2 Contents
Description
Comp #
Qty
Single
Double
Triple
Quad
Quint
Gearmotor, Hvy Duty (*Gearmotor, Extra Hvy Duty - A5299)
A5319
1
1
1
1
1
Rotating Contact
Varies
1
1
1
1
1
Pillow Block Bearing 1” (*Pillow Blk Bearing 1-1/4” - A5651)
A5649
1
1
1
1
1
Junction Switch Box
A8140
1
1
1
1
1
Tilt Switch
Varies
1
2
3
4
Bolt Sack, Track
Varies
1
1
1
1
1
Tie Bar 18” hole- to-hole (*Tie Bar 27” hole-to-hole - A59021)
A5897
-
-
2
2
2
*Used on 40’ Diameter & Larger Machines
Table 5 - Fastir Plus Only Hardware Carton #3 Contents
Description
Comp #
Qty
4-1/2”
Crosstube
5-1/2”
Crosstube
Safety Decal Package
A3399
A3399
1
Parts Sack Stationary Auger Kit
A3426
A3426
1
Motor Mount
A5209
A5209
1
Outside Stationary Carriage
A5250
A6140
1
Shield
A8508
A6120
1
Stationary Carriage Plate
A5245
A6115
2
Flinger
A5616
A5616
1
Bolt Sack, Supplemental
A6854
A6854
1
Bearing, 1” Flange
J0003
J0003
2
Belt
J0179
J0195
1
Pulley, 9” Single A Groove
J0355
J0355
1
Prevent Voiding Warranty Sticker
L0249
L0249
1
Warning, Keep Away Moving Parts
L0284
L0284
1
Important, Grain Level Sticker
L0304
L0304
1
Sukup Logo
L03171
L03171
1
Manual
L1413
L1413
1
Wire Ties, Bundle
L9999
L9999
1
Tools Required
 Wrenches: 5/16”, 7/16”, 1/2”, 9/16”, 3/4”, 10 mm wrench or adjustable (Crescent) wrench
 Hex (Allen) Wrenches: 1/4", 5/32”
 Regular-head Screwdriver
 Phillips-head Screwdriver
 Wire Stripper
 Punch
 Hammer
