SUMAVISION TECHNOLOGIES EMR3B User Manual

SUMAVISION EMR Operation Introduction
31 /53
parameter settings of 6-adjacent-channel QAM modulation card, as shown in the following
figure:
WEB Network Management Screen
Parameter
Range
Recommended
value
Channel
encoding mode
ANNEX_A/B
Set according to
the needs
Channel
bandwidth
6/8M
Set according to
the channel
encoding mode
Authorization
code
Output 1-6
Channels
No need to modify
QAM mode
64/128/256QAM
64QAM
Output frequency
52-940Mhz
Set according to
the needs
Output level
95-115dB
Set according to
the needs
RF switches
On/Off
Open with the
frequency point
setting
Symbol rate
5000-7000Khz
6875Khz
