SUMAVISION EMR Operation Introduction
3 /53
Chapter 2 Product Descriptions
2.1 Product Identification
There are product name, model and manufacturer, etc. on the front panel of EMR, as
shown in Fig. 2-1 EMR Front Panel.
Fig. 2-1 EMR Front Panel
Product name: Integrated Media Processing Platform
Model: EMR3.0, as shown in Fig. 2-2 EMR Front Panel.
Manufacturer: Sumavision Technologies Co., Ltd., as shown in Fig. 2-3 EMR Front
Panel.
Identification description: there’s the ex-factory identification on the rear panel of the
device, as shown in Fig. 2-2 Ex-factory Identification.
Fig. 2-4 Ex-factory Identification
Where, “S/N” refers to the ex-factory serial number, “EMR3B” stands for the device model
and “081006” is the production code.
2.2 Appearance
EMR appearance is shown as Fig. 2-3 EMR Appearance.
Fig. 2-3 EMR Appearance
2.2.1 Indicator
There are 8 indicators on EMR front panel, including:
Power
