SUMAVISION EMR Operation Introduction
40 /53
After the port is setting ok or the table is searched, if the port, CAS, EMM is already setting
ok, then we only need to do the scramble setting job. For the single PID scrambling, we
need to select the checkbox before the “Program list” to scrambling all PIDs. ECMPID
need to set ok, other scrambling parameters please under the guides of CAS setting.
After modifying the scrambling program, we must click button “Start Scramble” to make it
works. We suggest before the last click of “Start Scramble”, we have finished all the
parameters setting.
5.3.3 Port Setting
Port setting web page is displayed in Fig.Fig. 5-.
Fig. 5-11 Port Setting
First, select the card in the upper menu, which will refresh the corresponding ports and its
programs. (if no programs in one port it will not display). Default display is the main gigabit
card.
In the subgruop setting page, we select the CAS group corresponding to the port. Select
“Close” if no need to scrambling this port. Default setting is “Close”, all options in the
following page is gray, unsettable. Make it settable we need to select the subgroup.
The key mode can be randomly or fixed. If fixed mode is selected, we need to fill the value.
CAT fliter is for the scramble card to filter the orignial CAT information in the programs.
EMM1、2、3、4 respectly display the EMM setting for 4 simucrypt. EMM PID is set in the
frontt, and EMMG in the back.
After all the settings, click button “Submit”.
