INSTRUCTIONS MANUAL
-111-
FIG. 33
2
FIG. 34
1
l
FIG. 32
FILLING THE RECHARGEABLE COLLAPSIBLE UV
CONTAINER
N.B.: Using UV not recommended by the manufacturer will invalidate the warranty.
Procedure:
1. Press quick connection button (ref 1, Fig.32) to disconnect the UV container.
2. Lift the UV container out of its lodging (ref l, Fig.32),
3. Unscrew the cap (ref 2, Fig.33) and fill the container (Fig.34) with the required quantity
of UV for compressors.
4. Screw the cap (ref 2, Fig.33) back into the container.
5. Replace the container and hook it up to the quick connection taking care not to exert
pressure on the scale in order not to damage it.
NOTE: in order to reduce humidity and air contamination of UV, the collapsible container has
to be filled almost to the brim.
