SunFounder PiCrawler Kit
Note: This step only needs to be done once; afterward, simply insert other servo wires, and they will
automatically zero.
6. Now, remove the servo arm, ensuring the servo wire remains connected, and do not turn off the power. Then
continue the assembly following the paper assembly instructions.
Note:
• Do not unplug this servo cable before fastening this servo with the servo screw, you can unplug it after fastening.
• Do not turn the servo while it is powered on to avoid damage; if the servo shaft is inserted at the wrong angle,
pull out the servo and reinsert it.
• Before assembling each servo, you need to plug the servo cable into P11 and turn on the power to set its angle to
0°.
• This zeroing function will be disabled if you download a program to the robot later with the EzBlock APP.
86 Chapter 4. Play with Ezblock
