Sungrow SG320HX - Communication Parameters

93
Parameter
Explanation Range
QU_ExitPower Active power for Q(U) function deactivation
1% ~ 20%
QU_EnableMode
Unconditional activation/deactivation of Q
(U) function
Yes / No / Yes,
Limited by PF
QU_Limited PF
Value
PF value for Q(U) function activation
0~1.00
* Curve C is reserved and consistent with Curve A currently.
figure 7-16 Q(U) Curve
7.8.4 Communication Parameters
Serial Port Parameters
Tap Settings→Communication Parameters→Serial Port Parameters to enter the corre-
sponding interface, as shown in the following figure.
figure 7-17 Serial Port Parameters
table 7-11 Serial Port Parameters
Parameter
Range
Device Address
1–246
MPLC Parameters
Tap Settings→Communication Parameters→MPLC Parameters to enter the correspond-
ing interface, as shown in the following figure.
User Manual 7 iSolarCloud App
