7
2.2 Product Introduction
Model Description
The model description is as follows (take SG350HX as an example).
Appearance
The following figure shows the appearance of the inverter.
figure 2-2 Appearance
The image shown here is for reference only. The actual product received may differ.
No. Name
Description
1 LED indicator
To indicate the current working state of the inverter.
2 AC Wire Box
To connect AC cable and tracking system power cable in
this area.
3
External ground-
ing terminals
2, use at least one of them to ground the inverter.
User Manual 2 Product Description
