49
The screws on the sealing plate are captive screws, which will remain on the seal-
ing plate when the sealing plate is removed to avoid screw loss.
step 4 Cut off excess sealing ring according to the outer diameter of the cable.
step 5 Lead the cable with the protective layer removed through the sealing ring and fix the screws
on the bottom sealing plate.
step 6 Open the protection cover.
User Manual 5 Electrical Connection
