• If there is one wire per phase, with multi-core cable, the maximum communication dis-
tance is 1000 m.
• If there are two wires per phase, with multi-core cable, the maximum communication dis-
tance is 1000 m. The distance between two AC cables should be more than 15 cm. The
length of the two AC cables should be the same. If not, the length difference must be
smaller than 2m.
• The Data Logger is an optional device that can be ordered from SUNGROW.
• The Data Logger conducts data communication by directly using the AC output
cable of the inverter and thus saves the trouble to lay and maintain the special
communication cables. The RS-485 port of the Data Logger supports the
transparent transmission of the MODBUS-RTU and is completely compatible
with the monitoring devices and software of the original RS-485 communica-
tion method.
