36
Sunstone Welders User Manual: CDDP-A
If the welder is in a weld off state and receives a trigger this pop up will
appear notifying the user to switch to “Weld On”.
Once the number of weld count hits the limit dened by the user in the alarms
page this pop up will appear.
If the weld head doesn’t send a response back to welder to weld this pop up
will appear.
After overheating and once the welder is cooled this pop up will appear.
This error will appear if the capacitors take too long to charge while in Roll
Spot.
If the user disables the “Continue on Failure” slider in the Comparator tab,
and a comparator for Pulse1 fails, this error will appear.
If Pulse 1 is not enabled and user tries to enable comparator for Pulse 1 this
pop up will appear.
