Page | 71
SUNSYNK MAX | User Manual
APPENDIX B
Inverters sold in Australia will be set to the Default Australian standards
APPENDIX C
The Sunsynk Single-Phase Hybrid Inverter inverter is compatible with the SolarMan app, via a
Wifi or GSM data logger (See SolarMan instruction manual).
APPENDIX D
If an external Residual Current Device (RCD) is used it should be of Type A/AC with a tripping
current of 30mA or higher.
Use of RCDs
Residual Current Devices (RCDs): An RCD dedicated for an Inverter Energy System (IES) may
be used to meet the mechanical cable protection requirements of AS/NZS3000 for the cable
from the switchboard to the IES. If an RCD is installed the engineer must:
1. Disconnect all live conductors (including both active and neutral conductors) and
2. Be of the type specified in the inverter manufacturer’s instructions or as labelled on the in-
verter.
We recommend the use of an RCD on all circuits and sub-circuits connected to the Sunsynk
Inverter. Below is the specifications for a Residual Current Breaker with Overcurrent Protection
(RCBO)
Protocol Description
CAN
Pin 4: CAN-H
Pin 5: CAN-L
Pin 1, 2, 3, 6, 7, 8: NC
RS485
Pin 1: RS485B
Pin 2: RS485A
Pin 3, 6: GND
Pin 7: RS485A
Pin 8: RS485B
Pin 4, 5: NC
RS232
Pin 3: BMS transmit; Computer receiver
Pin 4: BMS receiver; Computer transmit
Pin 5: GND
Pin 1, 2, 6: NC
The following table is the connection on inverter side:
