Chapter 7: BIOS
7-11
CPU1 SLOT2 PCI-E 3.0 x8 Link Speed
This item confi gures the link speed of a PCI-E port specifi ed by the user. The
options are Gen 1 (Generation 1) (2.5 GT/s), Gen 2 (Generation 2) (5 GT/s),
and Gen 3 (Generation 3) (8 GT/s).
IOU1 (IIO1 PCIE Port 3)
Use this item to confi gure the PCI-E port Bifuraction setting for a PCI-E port speci-
fi ed by the user. The options are x4x4x4x4, x4x4x8, x8x4x4, x8x8, x16, and Auto.
CPU1 SLOT4 PCI-E 3.0 x8 Link Speed
This item confi gures the link speed of a PCI-E port specifi ed by the user. The
options are Gen 1 (Generation 1) (2.5 GT/s), Gen 2 (Generation 2) (5 GT/s),
and Gen 3 (Generation 3) (8 GT/s).
CPU1 SLOT5 PCI-E 3.0 x8 Link Speed
This item confi gures the link speed of a PCI-E port specifi ed by the user. The
options are Gen 1 (Generation 1) (2.5 GT/s), Gen 2 (Generation 2) (5 GT/s),
and Gen 3 (Generation 3) (8 GT/s).
IIO2 Confi guration
IOU2 (II02 PCIe Port 1)
This item confi gures the PCI-E port Bifuraction setting for a PCI-E port specifi ed
by the user. The options are x4x4, X8, and Auto.
CPU2 SLOT11 PCI-E 2.0 x4 (in x8) Link Speed
This item confi gures the link speed of a PCI-E port specifi ed by the user. The
options are Gen 1 (Generation 1) (2.5 GT/s), Gen 2 (Generation 2) (5 GT/s),
and Gen 3 (Generation 3) (8 GT/s).
CPU2 SLOT10 PCI-E 3.0 x8 Link Speed
This item confi gures the link speed of a PCI-E port specifi ed by the user. The
options are Gen 1 (Generation 1) (2.5 GT/s), Gen 2 (Generation 2) (5 GT/s),
and Gen 3 (Generation 3) (8 GT/s).
IOU0 (II02 PCIE Port 2)
Use this item to confi gure the PCI-E port Bifuraction setting for a PCI-E port speci-
fi ed by the user. The options are x4x4x4x4, x4x4x8, x8x4x4, x8x8, x16, and Auto.
To Next Page
