Chapter 6: Advanced Chassis Setup
6-1
Chapter 6
Advanced Chassis Setup
This chapter provides the procedures to install components and perform main-
tenance on the SC213XAC-R1K05 chassis. The only tool required is a Phillips
screwdriver.
Your system may require the installation of processors, memory, drives or expan-
sion cards. Other procedures presented in this chapter are for maintenance or
replacement.
5.25'' Drive Bay
VGA Port Serial Port
2 USB 3.0 Ports
2 USB 2.0 Ports
2 RJ45 GbE LAN Ports
Control Panel
Figure 6-1. Front and Rear Chassis Views
10 PCI-E 3.0 x8 (LP) Slots
PCI-E 2.0 x4 (LP) Slot
Dedicated IPMI LAN Port
Redundant 1000W
Titanium Level Power
Supplies
16 x 2.5'' Hot-swap SAS3/SATA3 Drvie Bays
System Status LEDs
Power
Button
Slim DVD/USB/COM Port Bay
