Supermicro SuperServer 2028R-TXR User Manual

5-26
SUPERSERVER 2028R-TXR User's Manual
BMC Heartbeat LED
A BMC Heartbeat LED is located at
LEM1 on the serverboard. When this
LED is blinking, BMC functions nor-
mally. See the table at right for more
information.
BMC Heartbeat
LED States
Color/State Defi nition
Green:
Blinking
BMC:
Normal
Note: For more information on SATA HostRAID confi guration, please refer to the
Intel SATA HostRAID User's Guide posted on our website at
http://www.supermicro.
com
SATA 3.0 Ports
Ten SATA 3.0 ports (I-SATA0-5, S-SATA0-3) are located on the motherboard.
I-SATA0-5 are supported by the Intel PCH, and S-SATA0-3 are supported by the
Intel SCU. I-SATA4/5 can be used with Supermicro SuperDOMs which are yellow
SATA DOM connectors with power pins built in, and do not require external power
cables. Supermicro SuperDOMs are backward-compatible with regular SATA
HDDs or SATA DOMs that need external power cables.
5-10 SATA Connections
