5-8
SUPERSERVER 2028R-TXR User's Manual
5-4 I/O Ports
Figure 5-3 shows the I/O ports on the rear of the system.
Figure 5-3. Rear Panel I/O Ports
1. COM Port 1 (Turquoise)
2. Back Panel USB 3.0 Port 4
3. Back Panel USB 3.0 Port 5
4. Dedicated IPMI LAN
5. Back Panel USB 2.0 Port 1
6. Back Panel USB 2.0 Port 2
7. LAN Port 1
8. LAN Port 2
9. VGA
10. UID Switch/UID LED (LED1)
1 9
8
7
5
10
3
2
4
6
