Chapter 7: BIOS
7-25
Super IO Confi guration
Super IO Chip AST2400
Serial Port 1 Confi guration/Serial Port 2 Confi guration
Serial Port 1/Serial Port 2
Select Enabled to enable the onboard serial port specifi ed by the user. The options
are Enabled and Disabled.
Device Settings
This item displays the base I/O port address and the Interrupt Request address of
a serial port specifi ed by the user.
Change Port 1 Settings/Change Port 2 Settings
This feature specifi es the base I/O port address and the Interrupt Request address
of Serial Port 1 or Serial Port 2. Select Auto for the BIOS to automatically assign
the base I/O and IRQ address to a serial port specifi ed.
The options for Serial Port 1 are Auto, (IO=3F8h; IRQ=4), (IO=3F8h; IRQ=3, 4, 5,
6, 7, 9, 10, 11, 12), (IO=2F8h; IRQ=3, 4, 5, 6, 7, 9, 10, 11, 12); (IO=3E8h; IRQ=3,
4, 5, 6, 7, 9, 10, 11, 12), and (IO=2E8h; IRQ=3, 4, 5, 6, 7, 9, 10, 11, 12).
The options for Serial Port 2 are Auto, (IO=2F8h; IRQ=3), (IO=3F8h; IRQ=3, 4, 5,
6, 7, 9, 10, 11, 12), (IO=2F8h; IRQ=3, 4, 5, 6, 7, 9, 10, 11, 12); (IO=3E8h; IRQ=3,
4, 5, 6, 7, 9, 10, 11, 12), and (IO=2E8h; IRQ=3, 4, 5, 6, 7, 9, 10, 11, 12).
Serial Port 2 Attribute
Select SOL to use COM Port 2 as a Serial_Over_LAN (SOL) port for console redi-
rection. The options are COM and SOL.
Serial Port Console Redirection
COM 1
COM 1 Console Redirection
Select Enabled to enable COM Port 1 Console Redirection, which will allow a client
machine to be connected to a host machine at a remote site for networking. The
options are Disabled and Enabled.
*If the item above set to Enabled, the following items will become available for
confi guration:
