Chapter 7: BIOS
7-29
Legacy OS Redirection Resolution
Use this feature to select the number of rows and columns used in Console
Redirection for legacy OS support. The options are 80x24 and 80x25.
Putty KeyPad
Use this item to confi gure the settings for the function keys and the key pad for
Putty, which is a terminal emulator designed for the Windows OS. The options
are VT100, LINUX, XTERMR6, SCO, ESCN, and VT400.
Redirection After BIOS Post
Use this feature to enable or disable legacy Console Redirection after BIOS
POST (Power-On Self-Test). When this feature is set to Bootloader, legacy
Console Redirection is disabled before booting the OS. When this feature is set
to Always Enable, legacy Console Redirection remains enabled upon OS boot.
The options are Always Enable and Bootloader.
Serial Port for Out-of-Band Management/Windows Emergency
Management Services (EMS)
The submenu allows the user to confi gure Console Redirection settings to sup-
port Out-of-Band Serial Port management.
EMS Console Redirection
Select Enabled to use a COM port selected by the user for EMS Console Redi-
rection. The options are Enabled and Disabled.
*If the item above set to Enabled, the following items will become available for
user's confi guration:
EMS Console Redirection Settings
Out-of-Band Management Port
The feature selects a serial port in a client server to be used by the Windows
Emergency Management Services (EMS) to communicate with a remote host
server. The options are COM1 (Console Redirection) and COM2/SOL (Console
Redirection).
Terminal Type
Use this feature to select the target terminal emulation type for Console Redirec-
tion. Select VT100 to use the ASCII character set. Select VT100+ to add color
and function key support. Select ANSI to use the extended ASCII character set.
Select VT-UTF8 to use UTF8 encoding to map Unicode characters into one or
more bytes. The options are ANSI, VT100, VT100+, and VT-UTF8.
