Chapter 4: AMI BIOS
4-67
•
Peripheral Temperature
- displays the detected peripheral d
e
-
vice temperature.
•
PCH Temperature
- indicates the detected PCH chip temperatur
e.
System
Health
The following items will be displayed (V
oltage):
•
VCPU
•
12V
•
VCPU_SA
•
5VCC
•
VDIMM
•
VCPU_IO
•
VCPU_GT
•
VDIMM_2.5
•
PCH 1.0V
•
3.3V_DL
•
VSB3
•
3.3VCC
•
VBAT
•
VCPU_STPLL
