Chapter 1: Introduction
1-3
Audio
One (1) High Denition Audio 7.1 channel connector
supported by Realtek ALC1150 on the back panel
One (1) Front Panel Audio Header
One (1) S/PDIF Out on the rear side of the chassis
Super I/O
Nuvoton NCT6792D-B
BIOS
128 Mb AMI BIOS
®
SPI Flash BIOS
Plug and Play (PnP0, DMI 2.8, PCI 2.3, ACPI
1.0/2.0/3.0, and USB Keyboard
Power Configuration
ACPI/ASPM Power Management
Main Switch Override Mechanism
Power-on mode for AC power recovery
Health Monitoring CPU Monitoring
Onboard monitors: VCPU, 12V, VCPU_SA, 5VCC,
VDIMM, VCPU_IO, VCPU_GT, VDIMM_2.5, PCH 1.0V,
3.3V_DL, AVCC, VSB3, 3.3VCC, VBAT, VCPU_STPLL
CPU 4+1 Phase Switching Voltage Regulator
GT 3 Phase Switching Voltage Regulator
CPU/System overheat LED and control
CPU Thermal Trip support
Thermal Monitor support
Fan Control
Fan status monitoring with rmware 4-pin fan
speed control
Low noise fan speed control
System Management
PECI (Platform Environment Conguration Inter-
face) 2.0 support
System resource alert via SuperDoctor
®
V
SuperDoctor V, NMI
Chassis Intrusion header and detection
CD Utilities
BIOS ash upgrade utility
Drivers and software for Intel® Z170/H170 Ex-
press chipset utilities
Other
ROHS 6/6 (Full Compliant, Lead Free)
Dimensions
ATX form factor (9.6" x 9.6") (243.84 mm x
243.84 mm)
