Chapter 2: Installation
2-29
A. STBY PWR
A
Standby Power Header
The Standby Power header is located
at STBY1 on the motherboard. See
the
table
on
the
right
for
pin
deni
-
tions.
Standby Power
Pin Denitions
Pin# Denition
1
+5V Standby
2
Ground
3
Wake-up
52
54
