Page #85 background imageLoading...
Page #85 background image
Chapter 4: AMI BIOS
4-15
DMI Link ASPM Control
Use this feature to set the ASPM (Active State Power Management) state on
the SA (System Agent) side of the DMI Link. The options are Disabled, L0s,
L1 and L0sL1.
PCH DMI Link ASPM Control
Use this feature to set the ASPM (Active State Power Management) state on
the device installed on the DMI Link supported by the PCH chip. The options
are Disabled and Enabled.
PCH SLOT1 / SLOT3 / SLOT5 PCI-E 2.0 X1 ASPM
This feature sets the ASPM (Active State Power Management) level for the
devices installed on PCI SLOT1, SLOT3 and SLOT5. The options are Disabled,
L0s, L1, L0sL1 and Auto.
Memory Conguration
This item displays the following information on the memory modules installed
on the motherboard.
•Memory RC Version
•Memory Frequency
•Total Memory
•Memory Voltage
•DIMM A1
•DIMM A2
•DIMM B1
•DIMM B2
•CAS Latency (tCL)
•Minimum Delay Time
•CAS to RAS (tRCDmin)
•Row Precharge (tRPmin)
•Active to Precharege (tRASmin)
