Superwind 350 - 5 Preparations for Assembly; Inspection and Unpacking; Inspection; Unpacking

© Copyright Mission Critical Energy Inc, 2019 Version 1-2019
www.superwind.com
13
5.
PREPARATIONS FOR ASSEMBLY
5.1 Inspection and Unpacking
5.1.1 Inspection
Visually inspect each shipping container immediately upon delivery for damage that
may have occurred during transportation. If damage is found, request a complete
inspection by the carrier’s driver and have him acknowledge the type and extent of
damage in writing on the Bill of Lading. If a claim needs to be filed with the carrier, it
must be filed within 24 hours of arrival. Claims for damage that occur during transit are
the sole responsibility of the buyer.
5.1.2 Unpacking
Upon opening the shipping container(s), visually inspect all system components for
signs of physical damage that may have occurred during shipping (scratches, loose
hardware, broken parts, etc).
5.1.3 Packing list:
PACKING LIST
Table 5.1.3
ITEM
DESCRIPTION
SIZE
QTY

1
Generator unit
48V
1
2
Hub
1
3
Wind vane
1
4
Rotor blade
3
5
Wind vane mounting plate
1
6
Plastic bushing (optional stainless steel bushing)
1
7
Socket cap bolt – [Rotor Hub Mounting Bolt]
M8 x 80
1
8
Socket cap bolt
M8 x 20
2
9
Socket cap bolt
M6x 25 (TUFLOK)
6
10
Socket cap screw with rubber ring
M6 x 8 (TUFLOK)
3
11
Hexagon socket button head screw
M6 x 12
2
12
Hexagon socket button head screw
M6 x 6
2
13
Allen key
6 mm
1
14
Allen key
5 mm
1
15
Allen key
4 mm
1
16
SCR 48V Charge Regulator
1
17
Stop Switch
1
18
Power resistor
5.6 Ohm, 400 Watt
1
19
Temp-Sensor
1
20
Operation manual
1
