8.
COMMISSIONING
Before initial operation of your new Superwind 350/48V verify correct installation using the
check list below.
8.1 Check List
done

Check List
Chart No. 8.1
Section:
Mast:
Assembled and erected in accordance to the respective manuals. Bolts, joints,
anchors and braces checked. Mast vertically adjusted.
7.3
Grounding / lightning protection:
Mast / support grounded.
6.4
Ground wire connected to the grounding bus.
6.4
Electrical system:
Batteries correctly installed and (if applicable) electrolyte at correct levels.
6.3.4
Charge Regulator SCR 48V correctly mounted and connected.
6.3.5
Power resistor correctly mounted and connected. Installation location provides
adequate heat dissipation.
6.3.8
10 amp fuse holders correctly installed and connected.
6.3.6
Stop switch correctly installed and connected.
6.3.7
Ammeter correctly installed and connected (optional).
Cabling in accordance with wiring diagram and correctly connected.
6.2
Polarity of all cables and connections verified as correct.
6.3.3
Wind Generator:
Cables connected with correct polarity.
6.3.3
Strain relief for cables provided (if necessary).
6.3.2
Yaw shaft correctly inserted into bushing and secured with screws.
7.2.
Wind vane correctly fastened with mounting plate screws tightened.
7.4.1
Rotor blades correctly fastened.
7.5
Rotor blade screws tightened at 4.5 Nm [3.32 lb/ft].
7.5.1
Hub mounted on the generator shaft and tightened at 18 Nm [13.27 lb/ft].
7.5.1
Once all installation work has been completed correctly and verified, install all fuses and place
the stop switch into the RUN-position. Your new Superwind 350/48V is now ready for
operation.
CONGRATULATIONS!
