The American Stainless Steel bushing is an option for use in
areas that experience extreme wind conditions. A detailed
description and installation instructions for this bushing are
provided with the unit.
The American Delrin
®
(White) and the American Delrin
®
(Black) bushings come with
predrilled holes to facilitate attachment to the yaw shaft and to the mast with their
respective hardware as follows (Fig. No. 7.2.2d).
Three (3) M6 x 8 Socket cap screws (with TUFLOK coated threads and rubber
rings) are included and are used to attach the bushing to the yaw shaft.
Two (2) M6 x 6 hexagon socket button head screws (also included) are used
to attach the bushing to the mast. These screws will extend into the groove of
the yaw shaft, but will not touch it. Optional M6 x 12 screws are also included
and may need to be used, depending on installation requirements.
The default bushing for the Superwind 350/48V is either the 2.08 inch (52.832mm)
Delrin
®
White bushing or the 2.055 inch (52.197mm) Delrin
®
Black bushing,
depending on the customer’s specific needs (if a stainless or aluminum pipe mast is
being used for example).
