Tools necessary for dismantling the various parts of the appliance Page 03
Removing the oscillating unit locking bolts Page 03
Step 1 Removing the top cover (A020) Page 04
Step 2 Removing the rear cover (A030) Page 04
Step 3 Removing the door gasket (E020) Page 04
Step 4 Removing the appliance door Page 04
Step 5 Removing the door handle assembly (E090) and/or the door surround (E050) Page 05
Step 6 Removing the door glass (E040) Page 05
Step 7 Removing the door hinge (A040) Page 06
Step 8 Removing door catch (E060) Page 06
Step 9 Removing the drive belt (G170) and/or driven pulley (G160) Page 07
Step 9 (For 39 cm and 33 cm washing machines) Removing:
the drive belt (G170) and/or driven pulley (G160) Page 07
Step 10 Removing the electronic module (A210) and/or the electronic module support (A200) Page 08
Step 10 (For 39 cm and 33 cm washing machines) Removing:
the electronic module (A210) and/or the electronic module support (A200) Page 08
Step 11 Removing:
- the power supply cable (D100)
- the suppressor (D060)
- the cable grommet and pressure switch mounting (D019)
- the pressure switch (D020) Page 09
Step 11 (For 39 cm and 33 cm washing machines) Removing:
- the power supply cable (D100)
- the suppressor (D240)
- the cable grommet (D070)
- the pressure switch (D020) Page 10
Step 12 Removing:
- the detergent dispenser (C010)
- the detergent feed/steam discharge coupling (C060)
- the detergent dispenser cover (C020) Page 11
Step 12 (For 39 cm and 33 cm washing machines) Removing:
- the detergent dispenser (C010)
- the detergent feed/steam discharge coupling (C060)
- the detergent dispenser cover (C020) Page 12
Step 13 Removing the wash motor (G130) Page 13
Step 14 Removing the solenoid valve (D010 and/or D300) and/or the internal water system Page 14
Step 15 Removing the wash water heater element (G140) Page 14
Step 16 Removing the thermistor (G005) and/or fixed thermostat (G560) Page 15
Step 17 Removing the upper counterweight (G020) Page 15
Step 17 (For 39 cm and 33 cm washing machines) Removing: the upper counterweight (G020) Page 16
Step 18 Removing:
- the tub back plate (G550)
- the drum (G530)
- the bearings (G220-G230) Page 17
Step 19 Removing and/or replacing:
- the drain hose (F090)
- the electric drain pump (F010)
- the union (F080) between the electric pump (F010) and the filter body (F020)
- the drain coupling (F070) between the tub and filter body (F020) Page 18
Step 20 Removing the tub (G030) and/or the lower counterweight (G080) Page 19
Step 21 Removing the detergent drawer handle (C040) from the Control Panel Page 20
Step 22 Removing the detergent drawer (C030) or drawer handle (C040) Page 20
Step 23 Removing the switch (B040) from the Control Panel Page 20
FOR MODEL with Display
Step 24 Removing:
- the knob (B059)
- the electric component cover plate (B032)
- the program selector (B022) Page 21
Step 25 Removing the led printed circuit board (B034) Page 21
Step 26 Removing the button circuit board+display (B021) Page 21
Step 27 Removing:
- the button mounting box (B061)
- the Control Panel buttons with gasket (B062) Page 21
FOR MODEL without display
Step 24 Removing and/or replacing:
- the knob (B059)
- the electric component cover plate (B032) Page 22
Step 25 Removing the button printed circuit board (B028) Page 22
Step 26 Removing the led printed circuit board (B034) Page 22
Step 27 Removing the Control Panel buttons with gasket (B062) Page 22
Step 28 Removing the Control Panel (B010) Page 23
