Supratec S200 - 4.2 Display

13
User Manual S200 Open
Update April 2018
4.2 Display
4.2.1 Graphic symbol
4.2.1.1 Main screen for visualization of measurements and related units:
02
7.89
mg/l
pH
7.82
pH
°C
29.3
°C
↓
Man→
Note:
The example display may differ depending on the device's configuration.
The displayed graphic symbols indicate which keys are available to operate the device.
↓ This indicates that you can switch to the operating level using the appropriate key.
→ This indicates that the command function switches from manual to automatic by
pressing the key.
4.2.1.2 Visualization:
↕→
Calibration
Temp. Compens./
Controller setting
Manual mode
Time / date
Basic settings
Service
Enter the code
Grey area  area of the menu not visible on the 4-line screen.
Note:
Grey area of the menu not visible on the 4-line screen.
↕ Indicates that the cursor can be moved up or down using the cursor keys.
→ The additional arrow on the right indicates that a sub-menu or input of numeric values can
be selected.
