5 Installation
5.1 Assignment of terminals
Option SD 1.Eing 1.dig Eing 2.dig Eing Rel. 1 Rel. 2 Rel. 3
10 11 12 13 1 2 20 21 22 23 24 25 80 81 82 83 84 85 L N PE
90 91 92 93 94 95 96 97 4 5 6 7 30 31 32 33 70 71 72 73 PE PE PE PE
2.RS485 1.RS485 2.Eing 3Eing Analog.Ausg Digit.Ausg.
Eing. = input Ausg. = output
5.1.1 Assignment of pins
Function
Terminals
Description
Power supply voltage
L/N/PE
230 V/AC ± 10 % (50/60 Hz)
PE distribution block
PE, PE, PE, PE
PE distributor
Digital input 1
20+21+22
Digital input 21/22 (contact
without potential)
Electronic contact, 12V power supply
voltage
20/-22
Pulse 21
Digital input 2
23+24+25
Digital input 24/25 (contact
without potential)
Electronic contact, 12V power supply
voltage
+23/-25
Pulse 24
Analog output 1
0 / 4-20 mA max. load 500Ω
30+31
-30/+31
Analog output 2
0 / 4-20 mA max. load 500Ω
32+33
-32/+33
Digital output 1
Max. load 200 mA / 30V
70+71
Digital output for electronic monitoring
Dosing pumps
Digital output 2
Max. load 200 mA / 30V
72+73
Digital output for electronic monitoring
Dosing pumps
Switching from output relay 1
80+81
Potential-free contact
Switching from output relay 2
82+83
Potential-free contact
Switching from output relay 3
84+85
Potential-free contact
