Supratec S200 - 2 Technical Data; 2.1 General Overview

9
User Manual S200 Open
Update April 2018
2 Technical data
2.1 General overview
Article
Adjustment ranges
Power supply unit
230 V/AC ± 10 % (50/60Hz)
117 V/AC ± 10 % (50/60Hz)
Power consumption
16 VA
Level of protection
IP 65
Fuse (device)
80 mAT (230V)
160 mAT (117V)
Electrical properties of the
contact relay
Max. direct current/max. start-
up current
Rated voltage/max. switching
voltage
Max AC switching capability
to direct current
6A/16A
250VAC, 24VDC
6A
6A
Operating temperature
-20° to 50°C
Permissible storage temperature
-20°C to +65°C
Permissible humidity
Max. 90% to +40°C (non-
condensing)
Device dimensions
166 x 161 x 73.5 mm (l x h x d)
Weight
Approx. 1.1 kg
Warning:
Unit fuse of 16A max.
