User Manual S200 Open
Update April 2018
4.2.3 Example of access to a sub-menu, selection of "Temperature Compensation”
menu
Calibration
↕→
Temp. Compens./
Controller setting
Manual mode
…
Use the key to select the "temperature compensation” sub-menu.
↕→
Temp. Compens./
Manual Comp.
Default temp.
25.0°C
Use the key to switch the temperature compensation mode from automatic to
manual. If the temperature is compensated automatically, Pt100 / Pt1000 is used.
↕→
Temp. Compens./
Automat. Comp.
Default temp.
25.0°C
Use the … key to select the settings input.
