Working direct.
Reduce
Controller output
↕→
Relay 1
The operator may choose: relay 1, relay 2, digital output 1, digital output 2, analog output 1
or analog output 2.
8.4 Pulse frequency
The controller output is switched so as to pulse the frequency by means of the pulse setting. A
0 p/h setting allows the controller to switch for controller pulse intervals. The numerical value
such as 36 p/h indicates that 3,600 pulses/hour are released at 100% of dosage capacity.
Controller output
Relay 1
Pulse frequency
↕→
100* 0 P/h
The right arrow lets you change the pulse numerical value.
Controller output
Relay 1
Pulse frequency
←
100* 0↕P/h
8.5 Checking the pulse frequency
The pulse interval time setting determines the total pulse interval time. A controlled variable of
50% indicates that the pulses and interval time are of equivalent duration when the value is
set to 10 sec., in this case, it would return to 5 seconds.
A controlled variable of 0 % indicates no pulse.
A controlled variable of 100% indicates no interval.
Pulse frequency
100* 36 P/h
Pulse interval
↕→
10s
