Supratec S200 - 7.2.4 Configuration of the Nephelometric Turbidity Measurement

33
User Manual S200 Open
Update April 2018
7.2.3 Sensor information
The operator has access to information on the connected sensor from the main SERVICE menu.
Manual mode
Time / date
Basic settings
↕→
Service
Display setting
Device data
Analog inputs
↕→
Turbidity meas.
Pressing the right arrow in the TURBIDITY MEASUREMENT LINE gives access to the following
information:
• Sensor serial number
• Software version
• Hardware version
• Instant measurements of all available parameters for the sensor in question.
7.2.4 Configuration of the nephelometric turbidity measurement
The BASIC ADJUSTMENT submenu provides access to the digital nephelometric turbidity
sensor configuration. In this case, the sensor work range is selected from among the four
provided.
Correct. PT
↕→
Turbidity meas.
Controller param.
Switch-on delay
The first RANGE line on this screen is used to select the range of measurement from among the
4 available:
0-50; 0-200; 0-1,000 or 0-4,000 NTU
Turbidity meas.
↕→
Range 0-50 NTU
Temperature
measurement
23.27°C
