User Manual S200 Open
Update April 2018
8 Controller adjustments
8.1 Allocation of controller values
Up to four individual controllers can be assigned to different values.
One or more controllers can be enabled in the BASIC/CONTROL PARAM. ADJUSTMENT
submenu.
The operator then has 4 choices.
↕→
Setting contr.1
Setting contr.2
Setting contr.3
Setting contr.4
An initial choice allows the operator to define the measurement related to this controller.
• Temperature measurement
• Turbidity measurement
• Ox. digital sensor
• MES-Turb. measurement
• pH digital sensor
• No measurement.
8.2 Controller action direction
Controller 1
↕→
No measurement
Working direct.
Reduce
The controller action direction shall be determined using the REDUCE/INCREASE
adjustment. For example, REDUCE indicates that the controller is running when the value is
greater than the pre-determined set point. As a result, the value decreases (lower value).
8.3 Assignment of controller output
The controller output signal may be assigned to various actuators (relay, etc.).
