18
User Manual S200 Open
Update April 2018
Union
Terminals
Description
Modbus RS485 interface for
connecting digital probes
12VDC power supply voltage
12 V DC max. 200 mA
90+91+92+93+94
90 = 0 V, 91 = +12 V,
92 = B, communication
93 = A, communication
94 = shielding
Modbus RS485 interface
for communication with
the
management system
95+96+97
95 = B
96 = A
97 = shielding
