Supratec S200 - 7.1.2 Setting; Configuring of Displayed Measurements

22
User Manual S200 Open
Update April 2018
↕→
Correct. PT
Controller param.
Switch-on delay
Analog output
Digi. Input 2
↕→
Select parameters
Language
Bus address
The SELECT PARAMETERS leads to the list of active parameters from 1 to 6. These are the 6
usable display areas on the screen.
↕→
Parameter 1
Parameter 2
…
Selecting one of the six parameters leads to a list of choices:
- No measurement
- Temperature measurement
- Turbidity measurement
- Oxygen digital sensor
- MES-Turb. measurement
- pH digital sensor.
In this case, the temperature or oxygen will be selected as these 2 parameters are delivered by
the OPTOD sensor.
Parameter 1
↕→
Oxygen dig. sensor
Note that these two parameters can be viewed simultaneously by configuring parameters 1 and
2.
Parameter 2
↕→
Temp. measurement
