Mechanical Stationary
Operator’s Manual
300-0804 © 05/2020
ADDITIONAL OPTIONS
Rubber Extension
The rubber extension option is a heavy duty, maintenance-free 1/2 in (12.7 mm) thick rubber belting, bolted along the
inside ring of the tub. A stiffener is also added to the side walls for additional rigidity and to prevent collapse during
loading.
This option is not intended to increase the tub capacity of holding more feed; it is to minimize the spillage of a mix with a
high percentage of roughage loaded into the tub.
Figure 27
Rubber Extension
Stiffener
Magnetic Drop Chute
Chute magnets () are designed to reduce the possibility of metallic contamination in your livestock. On a
stationary mixer, magnets can be installed in the drop chute. Debris should be removed from the magnets daily.
Magnetic drop chutes can be installed on both end or side door discharges.
Figure 26
Drop Chute Shown with Magnets
