APPENDIX G - WEIGHBAR CALIBRATION CHARTS
Refer to SETTING OF PARAMETERS or CALIBRATION in the owner’s manual for this procedure.
CAL value kg CAL value lbs
2-1/8 in. DIA MOBILE PRT2003 3 0.30 mV/V = 6,000 lbs 5,005 11,034
2-1/8 in. DIA MOBILE PRT2003 4 0.30 mV/V = 6,000 lbs 6,674 14,713
2-7/8 in. DIA MOBILE PRT2004 4 0.75 mV/V = 15,000 lbs 6,674 14,713
2-7/8 in. DIA MOBILE PRT2004 6 0.75 mV/V = 15,000 lbs 10,010 22,067
Dinamica Generale Set-up Calibration Numbers
SUPREME LOAD CELL
MODEL
SUPREME
PART
NUMBER
# OF LOAD
CELLS
INSTALLED
mV/V @ WEIGHT
DG Microcomputer
PASSWORD 12
set-up # calibration #
2-1/8 in. DIA MOBILE DIGI400770 3 0.30 mV/V = 6,000 lbs 300 146006 24480
2-1/8 in. DIA MOBILE DIGI400770 3 0.30 mV/V = 6,000 lbs 400 146010 24480
2-1/8 in. DIA MOBILE DIGI400770 3 0.30 mV/V = 6,000 lbs 500, 600 146014 24480
2-1/8 in. DIA MOBILE DIGI400770 4 0.30 mV/V = 6,000 lbs 500T, 600T, 700T 146014 32640
2-1/8 in. DIA MOBILE DIGI400770 4 0.30 mV/V = 6,000 lbs 900T 146024 32640
2-7/8 in. DIA MOBILE DIGI403271 4 0.75 mV/V = 15,000 lbs
1000T, 1200T, 1400T
126040 33812
2-7/8 in. DIA MOBILE DIGI403271 6 0.75 mV/V = 15,000 lbs 1500TR, 1700TR 126050 48650
Digi-Star Set-up Calibration Numbers
DIGI-STAR LOAD CELL
MODEL
SUPREME
PART
NUMBER
# OF LOAD
CELLS
INSTALLED
mV/V @ WEIGHT SUPREME MODEL
DIGI-STAR Microcomputer
